产品参数
YZS-PN6060
效率: 90%
品牌: 亿智顺
显色值: 80
防水等级: IP20
灯珠品牌: 三安
灯珠型号: 2835
外壳颜色: 银色
灯珠色温: 3000-6500k/RGB
输入电压: AC85-265V
外壳材质: 铝+PS
产品详情

Advantages of NGE LED Panel Light

Product Specification

Specification for China Ceiling Surface Mounted Ultra Slim Square 36W 40W LED Panel Light 62X62 600X600 60X60 Price

General

Information

Product Type36W 40W LED Panel Light 62X62 600X600 60X60
Product SizeL595mm*W595mm
Product ColorWhite
     Electric          parameter Driver BrandCE, TUV, SAA approved
Input VoltageAC100-240V/50-60Hz
Power40W
PF>0.90
   Optical   Parameter
LED BrandEpistar chip, 2835 SMD
CRI>80
Color Temperature (CCT)2700K-7000K
Luminous Flux4400lm±5%

Luminous Efficiency

110lm/w
Beam angle 120°
OthersLifetime50,000Hr
Operating temperature-30℃~45℃
Warranty5 years
MaterialsAL housing+PMMA
Instrallation typerecessed, suspending, surface mounted
Applicationoffice, shop, hospital, supermarket.,etc.

Series Products of China Ceiling Surface Mounted Ultra Slim Square 36W 40W LED Panel Light 62X62 600X600 60X60 Price

110lm/w High output LED Panel Light Series:


130lm/w Ultra output LED Panel Light Series:


Item No.Input VoltagePowerLuminous FluxLuminous EfficiencyCRIPF
YZS-PN3060-AA36AC100-240V36W4500lm±5%120-130lm/w>80>0.90
YZS-PN6060-AA36AC100-240V36W4500lm±5%120-130lm/w>80>0.90
YZS-PN6060-AA48AC100-240V48W6000lm±5%120-130lm/w>80>0.90








支持定制
支持开发
